10-inch Facial Recognition Binocular Multifunctional
Android / 3000~30000 pcs Fingerprint / 50000 pcs Face / Multiple Card
BD1012 indoor face recognition terminal
This product is the All-in-one version of the entire 10" series, with a 4-core RK3288 processor and Android system.
Not only is it equipped with the most advanced binocular face recognition system, it is also equipped with fingerprint, RFID, QR Code and Barcode recognition in order to meet customer needs. Different identification methods can be used for complex people in complex scenarios to improve your management efficiency.
Specification
| Item | Parameter |
| Dimension | 310×175×32(mm) |
| Weight | About 1.2kg |
| CPU | RK3288 Cortex-A17，quad-core 1.6G |
| GPU | Mali-T760MP4 |
| Flash | RAM 2GB |
| ROM 16GB | |
| OS | android8.1 |
| Communication | 10/100/1000Mbps Ethernet |
| LCD | 10.1 inch IPS HD(1280*800)；brightness 400cd/㎡ |
| Speaker | inside speaker，1.5W， |
| camera | RGB camera: 2M, capture frame rate 25-25 IR camara: 2M,capture frame rate 25-25 |
| TP | 5 points Capacitive touch panel， reponse time＜48ms， surface hardness＞6H, transmittance≥85% |
| Relay | Support 3 channel NO,NC,COM |
| RJ45 | Support |
| USB HOST | USB2.0 |
| SD card | Support SD card：32GB |
| Wiegand | input or output ，TYP input |
| GPIO | Support 2 channel（door magnets, door opening buttons） |
| Adapter | DC12V-2A |
| Power | TYP：＜10W |
| MAX：＜15W | |
| Operation Temperature |
0℃-45℃ |
| Operation humility |
10%-90% No condensation |
| Storage Temperature |
-10℃~+60℃ |
| Storage humility |
20%-90% No condensation |
| ESD | ±6kV touch、±8kV Air |
| IC reader | 13.56MHz，support M1/CPU，speed <0.1s Distance ：2.5-5cm |
| ID reader (optional) |
Distance：0-5cm frequency：125KHz peed <0.1S |
| QR reader (optional) |
Image(Pixels): 640 pixels(H) * 480 pixels(V) FPS: 1/60s Roll/Pitch/Yaw: 360°，±55°，±55° Decode capability: QR、Data matrix、PDF7、Chinese information code Minimum Resolution: ≥7.5mil |
| POE (optional) |
Optional，IEEE802.3AT |
| WIFI+Blue tooth (optional) |
IEEE802.11 b/g/n （2.4G）+Bluetooth 4.0 |
| 4G (optional) |
antenna：insde antenna 4G Support |
| Face recognition | 1：N Speed：≤1S 1：1Speed：≤1S Face library：50000 Distance：TYP 1M，Max 2M； visual angle：vertical ±35°，transverse±30°， Support Life detection |
| Fingerprint | finger library：3000/10000/30000 recorder type：photoelectric type Fingerprint registration times：3 times fingerprints allowed to register：10/person FAR：＜0.0001 % FRR：＜0.1 % speed：＜2S |
